PV/EL

The PV/EL Type PROTEGO® valve is a highly developed combined pressure and vacuum relief valve Válvula de presión y vacío A pressure and vacuum relief valve is a pressure equalization valve for impermissible pressure and vacuum in a closed system. . It is primarily used as a device Bastidor A device is a pipe component that influences the media flow by opening, closing, or partially shutting off the flow channel or by dividing or mixing the media flow. for relieving pressure Presión de apertura The relieving pressure is the vacuum or overpressure at which the valve reaches the lift required for the mass flow to be discharged. and vacuum Vacío Vacuum is the pressure in an enclosed space that is lower than the ambient pressure. in tanks, containers, and process engineering equipment Equipment Machines, appliances, fixed or mobile devices, control parts and accessories, and warning and prevention systems, whether separate or combined, intended for the generation, transfer, storage, measurement, control, and conversion of energy, and for the processing of materials, which have their own potential source of ignition and may cause an explosion. . The valve offers reliable protection against unallowable overpressure Presión excesiva Overpressure refers to an increase in pressure in a system or vessel above the normal operating pressure. and underpressure. Product Product Includes equipment, protective systems, devices, components and combinations of these. loss close to the set pressure Presión de reacción Set pressure is the gauge pressure at the device inlet at which the relief device is set to start opening under service conditions. is avoided and unallowable product entry is prevented.

Due to the highly developed manufacturing technology, the tank pressure Presión del tanque Tank pressure is the pressure within a tank. is maintained up to the set pressure with a tightness that is far superior to the conventional standard. This feature is achieved by valve seats made of high quality stainless steel and with precisely lapped valve pallets (1) or with an air cushion seal Sello A seal prevents or limits unwanted transfer of product from one container to another. Seal is used as superordinate term for all types of sealing elements. (2) in conjunction with high quality FEP diaphragm Membrana A diaphragm is a thin layer of material, which has a large surface area. . The valve pallets are also available with a PTFE seal to prevent the valve pallet Disco de la válvula Valve pallet is the generic term for the assembly that rests on the valve seat. from sticking when sticky products are used, and they enable the use of corrosive substances. After the overpressure is released or the vacuum is balanced, the valve re-seats and provides a tight seal. The optimized fluid dynamic design of the valve body and valve pallet is a result of many years of research, resulting in stable operation of the valve pallet, optimized performance, and reduced product losses.
