Standardization Committees

International Standard for Flame Arresters – ISO 16852

EN 12784 was replaced by EN ISO 16852 as a harmonized standard under the then Directive 94/9/EC with effect from January 1, 2011. The international ISO standard ISO 16852 was adopted as European standard EN ISO 16852:2010 "Flame arresters - Performance requirements, test methods and limits for use". It thus replaced EN 12874 with the same title. The replacement of this standard was not due to safety-related reasons, but resulted from the extension of the standard's scope of validity beyond Europe. Flame arresters complying with EN 12874 therefore continued to fulfil the essential health and safety requirements of Directive 94/9/EC, now 2014/34/EU.
Work was then carried out on a first revision of the ISO standard, in particular with regard to the testing of high-speed valves. This EN ISO 16852:2016 replaced the 2010 edition on November 1, 2017.
Work is currently underway to incorporate the standard for flame arresters into the ISO 80079-xx series of standards, which will also be adapted to IEC requirements. The ISO/IEC 80079-49 standard will be published soon.

Standards for venting atmospheric and low-pressure storage tanks - ISO 28300 and API 2000

The International Standard ISO 28300 and the 6th edition of API 2000 are identical in content and specify the requirements for normal venting and emergency venting of aboveground tanks for the storage of liquid petroleum or petroleum products and of aboveground and underground storage tanks with refrigeration designed to operate at full vacuum Vacuum Vacuum is the pressure in an enclosed space that is lower than the ambient pressure. to 1.034 barg (15 psig). This standard, entitled "Petroleum, petrochemical and natural gas industries - Venting of atmospheric and low-pressure storage tanks", covers the causes of overpressure Overpressure Overpressure refers to an increase in pressure in a system or vessel above the normal operating pressure. and vacuums, the specification of venting and venting requirements, the equipment Equipment Machines, appliances, fixed or mobile devices, control parts and accessories, and warning and prevention systems, whether separate or combined, intended for the generation, transfer, storage, measurement, control, and conversion of energy, and for the processing of materials, which have their own potential source of ignition and may cause an explosion. required, the selection and installation of venting and venting equipment and the testing and marking of venting equipment. This standard is intended for tanks containing petroleum and petroleum products, but is also applicable to tanks containing other liquids.
In the meantime, the API had further developed the API 2000 standard in a 7th edition. In order to achieve the goal of making both standards identical again, a revision of ISO 28300 is currently being processed, which is also being discussed in parallel at API.

Safety Design Principles Standards Committee (NASG)

As an overarching committee, the NASG (Standards Committee Safety Design Principles) carries out standardization work with regard to the testing and use of explosion protection Explosion protection An explosion protection is a flame arrester that prevents flame propagation into plant sections to be protected during explosions. devices (except flame arresters). Directive 2014/34/EU applies to equipment and protective systems intended for use in potentially explosive atmospheres (ATEX Directive). It lays down basic health and safety requirements that must be complied with by manufacturers of such equipment and systems. The NASG is actively involved in the development of standards that specify the basic requirements of the directive in detail. The standardization includes explosion prevention systems or protective systems for pressure relief and much more.
