BE/HK-E-IIB1

The Pressure/vacuum relief valve Pressure/vacuum relief valve is an umbrella term that includes pressure or vacuum relief valve as well as pressure and vacuum relief valve. PROTEGO® BE/HK-E End-of-Line Deflagration Flame Arrester Deflagration flame arrester Flame arrester designed to prevent the transmission of a deflagration. It can be an end-of-line flame arrester or an in-line flame arrester. was specifically developed for vessels which are not pressurized and store ethanol or other alcohols. The combustion of alcohol requires a modified Flame Arrester Flame arrester Device fitted to the opening of an enclosure, or to the connecting pipe work of a system of enclosures, and whose intended function is to allow flow but prevent the transmission of a flame. Element design to provide protection against endurance burning Endurance burning Stabilized burning for an unlimited time. . In addition, the device Device A device is a pipe component that influences the media flow by opening, closing, or partially shutting off the flow channel or by dividing or mixing the media flow. provides protection against atmospheric deflagration Deflagration Explosion propagating at subsonic velocity (EN 1127-1:1997). . It is typically installed on in-breathing and out-breathing vent lines to prevent flame transmission into the vessel Vessel Container or structural envelope in which materials are processed, treated or stored. or plant caused by endurance burning or atmospheric deflagration.

The PROTEGO® BE/HK-E End-of-Line Deflagration Flame Arrester is available for alcohols and other substances with MESG ≥ 0,85mm. The standard design can be used for operating temperatures up to +60°C / 140°F. EU conformity according to the currently valid ATEX directive. Approvals according to other national/international regulations on request.
