Apagallamas en línea bidireccionala prueba de detonaciones estables y deflagraciones en diseño lineal con tubo de choque, bidireccional
Features
Use of Patented Shock Wave Guide Tube Effect (SWGTE)
low number of FLAMEFILTER® discs due to the patented Shock Wave Guide Tube Effect (SWGTE)
Optimized Performance
due to the patented Shock Wave Guide Tube Effect (SWGTE)
Extended Application Range
for elevated operating temperatures and pressures
Spare Parts
cost-effective flame arrester / spare parts
Low Costs
low operating and lifecycle costs
Maintenance-Friendly PROTEGO® Flame Arresters
use of
maintenance
Maintenance
Combination of all technical and administrative actions, including supervision actions, intended to maintain or restore a unit in working order.
-friendly
PROTEGO® flame arrester unit
PROTEGO® flame arrester unit
The PROTEGO® flame arrester unit is the main component of a flame arrester. It prevents flame propagation.
possible
Temperature Sensors Possible
use of temperature sensors for G 1½ and G 2 is possible
Bi-Directional Flame Transmission
proof design
Differnt Series
allow increase of FLAMEFILTER® size for given flange connection resulting in lower pressure drop across the
device
Device
A device is a pipe component that influences the media flow by opening, closing, or partially shutting off the flow channel or by dividing or mixing the media flow.
Function and Description
Minimal Pressure Losses with Maximum Safety
The in-line
detonation flame arresters
Detonation flame arrester
Flame arrester designed to prevent the transmission of a detonation.
type PROTEGO® DA-SB are the newest generation of
flame arresters
Flame Arresters
A flame arrester, deflagration arrester, or flame trap is a device or form of construction that will allow free passage of a gas or gaseous mixture but will interrupt or prevent the passage of flame.
. Based on flow and
explosion
Explosion
Abrupt oxidation or decomposition reaction producing an increase in temperature, pressure, or in both simultaneously.
dynamic calculations as well as decades of field tests, a
product
Product
Includes equipment, protective systems, devices, components and combinations of these.
line was developed that offers minimum pressure losses with maximum safety. The flame arrester uses the Shock Wave Guide Tube Effect (SWGTE) to separate the flame front and shock wave. The result is an in-line detonation arrester without a classic
shock absorber
Shock absorber
A shock absorber is a device that reduces the kinetic energy of a detonation.
, which minimizes the use of FLAMEFILTER® discs.
Main component - PROTEGO® flame arrester
The devices are symmetrical and offer bi-directional flame arresting for deflagrations and stable detonations. The arrester essentially consists of two
housing
Housing
A housing is a solid shell, which surrounds a content, either protecting the content from external influences, or protecting the environment from the content.
parts with an integrated shock tube (1) and the PROTEGO®
flame arrester unit
Flame arrester unit
Flame arrester casing with FLAMEFILTER® set.
(2) in the center. The PROTEGO® flame arrester unit is modular and consists of several FLAMEFILTER® discs (3) and spacers firmly held in a
FLAMEFILTER® casing
FLAMEFILTER® casing
Enclosure for FLAMEFILTER® including insert rings.
. The number of FLAMEFILTER® discs and their gap size depends on the arrester‘s intended use.
Suitable for All Explosion Groups
By specifying the operating conditions, such as the temperature, pressure, explosion group, and the composition of the fluid, the optimum detonation arrester can be selected from a series of approved devices. The PROTEGO® DA-SB flame arresters are available for all explosion groups.
The standard design can be used with an
operating temperature
Operating temperature
Temperature reached when the equipment is operating under design conditions.
of up to +60°C / 140°F and an absolute
operating pressure
Operating pressure
Operating pressure is the pressure existing at normal operating conditions within the system being protected.
up to bar / 15.9 psi. Numerous devices with special approval for higher pressures (see table 3) and higher temperatures are available upon request. EU conformity according to the currently valid ATEX directive. Approvals according to other national/international regulations on request.
Product Data and Features
Dimensiones
Para seleccionar la serie y tamaño nominal (DN) – la combinación del ancho nominal (NG), rogamos utilicen el diagrama de flujo volumétrico indicado a continuación
| estándar | |||||||||||||
| NG | 150 / 6" | 150 / 6" | 200 / 8" | 300 / 12" | 400 / 16" | 500 / 20" | 600 / 24" | 700 / 28" | 800 / 32" | 1000 / 40" | 1200 / 48" | 1600 / 64" | |
| DN | ≤50 / 2" | 65, 80 / 2½“, 3 | ≤100 / 4" | ≤150 / 6" | ≤200 / 8" | ≤250 / 10" | ≤300 / 12" | ≤350 / 14" | ≤400 / 16" | ≤500 / 20" | ≤600 / 24" | ≤800 / 32" | |
| a | 285 / 11.22 | 285 / 11.22 | 340 / 13.39 | 445 / 17.52 | 565 / 22.24 | 670 / 26.38 | 780 / 30.71 | 895 / 35.24 | 1015 / 39.96 | 1230 / 48.43 | 1455 / 57.28 | 1915 / 75.39 | |
| b | IIA-P1,1 | 388 / 15.28 | 388 / 15.28 | 476 / 18.74 | 626 / 24.65 | 700 / 27.56 | 800 / 31.50* | 1000 / 39.37* | 1200 / 47.24 | 1400 / 55.12 | 1600 / 62.99 | 1800 / 70.87 | 2200 / 86.61** |
| IIA-P1,4-X3 | 400 / 15.75 | 400 / 15.75 | 488 / 19.21 | 626 / 24.65 | 700 / 27.56 | 800 / 31.50 | 1000 / 39.37 | 1200 / 47.24 | 1400 / 55.12 | ||||
| IIB3-P1,1 | 400 / 15.75 | 412 / 16.22 | 500 / 19.69 | 650 / 25.59 | 724 / 28.50 | 824 / 32.44 | 1000 / 39.37 | 1200 / 47.24 | 1400 / 55.12 | 1600 / 62.99 | 1800 / 70.87 | ||
| IIB3-P1,4-X3 | 412 / 16.22 | 412 / 16.22 | 512 / 20.16 | 650 / 25.59 | 724 / 28.50 | 824 / 32.44 | 1000 / 39.37 | 1200 / 47.24 | 1400 / 55.12 | ||||
| IIC-P1,1 | 400 / 15.75 | 400 / 15.75 | 500 / 19.69 | 638 / 25.12 | 700 / 27.56 | 788 / 31.02 | 1000 / 39.37*** | 1200 / 47.24*** | 1400 / 55.12*** | ||||
| c | 500 / 19.69 | 500 / 19.69 | 520 / 20.47 | 570 / 22.44 | 620 / 24.41 | 670 / 26.38 | 720 / 28.35 | 770 / 30.31 | 820 / 32.28 | 950 / 37.40 | 1050 / 41.34 | 1250 / 49.21 |
Dimensiones en mm / pulgadas
tamaños especiales hasta DN 1000 / 40“, NG 2000 / 80“ disponibles
* dimensión b sólo para P1.1 / 15.9
** tamaños especiales hasta DN 1000 / 40“, NG 2000 / 80“ disponibles
*** EN 12874
Selección del grupo de explosión
| MESG (Intersticio) | Gr. de explosión (IEC / CEN) | Grupo de gas (NEC) |
| > 0,90 mm | IIA | D |
| ≥ 0,65 mm | IIB3 | C |
| < 0,50 mm | IIC | B |
Homologaciones especiales bajo petición
Selección de la máxima presión de operación
| Expl. Gr. | DN | 50 / 2" | 80 / 3" | 100 / 4" | 150 / 6" | 200 / 8" | 250 / 10" | 300 / 12 " | 350 / 14" | 400 / 16" | 500 / 20'' | 600 / 24" | 800 / 32" |
| NG | 150 / 6'' | 150 / 6'' | 200 / 8'' | 300 / 12'' | 400 / 16'' | 500 / 20'' | 600 / 24'' | 700 / 28'' | 800 / 32'' | 1000 / 40'' | 1200 / 48'' | 1600 / 64'' | |
| IIA | Pmax | 2,1 / 30.5 | 2,1 / 30.5 | 2,1 / 30.5 | 2,1 / 30.5 | 2,1 / 30.5 | 2,1 / 30.5 | 1,4 / 20.3 | 1,4 / 20.3 | 1,4 / 20.3 | 1,1 / 15.9 | 1,1 / 15.9 | 1,2 / 17.4 |
| IIB3 | Pmax | 1,4 / 20.3 | 1,4 / 20.3 | 1,4 / 20.3 | 1,8 / 26.1 | 1,8 / 26.1 | 1,8 / 26.1 | 1,8 / 26.1 | 1,4 / 20.3 | 1,4 / 20.3 | 1,1 / 15.9 | 1,1 / 15.9 | - |
| IIC | Pmax | 2,2 / 31.9 | 2,2 / 31.9 | 1,1 / 15.9 | 1,1 / 15.9 | 1,1 / 15.9 | 1,1 / 15.9 | 1,1* / 15.9 | 1,1* / 15.9 | 1,1* / 15.9 | - | - | - |
Pmax = máxima presión de operación permitida en bar / psi absoluto, presiones de operación más altas bajo demanda
Tamaños intermedios hasta Pmáx bajo demanda
* diagramas de flujo volumétrico bajo demanda
Especificación de la máx. temperatura de operación
| ≤ 60°C / 140°F | ≤ 200°C / 392°F | Tmáx - Temperatura máxima de operación admisible en °C |
| - | X3 | Designation |
Temperaturas de operación más altas bajo demanda
Tipo de bridas de conexión
| EN 1092-1; Form B1 |
| ASME B16.5 CL 150 R.F. |
Otros tipos bajo petición
Modelo y especificación
Hay cuatro modelos diferentes disponibles:Apagallamas básico en línea a prueba de detonacionesDA-SB- – - –
Apagallamas en línea a prueba de detonaciones con sensor de temperatura integrado* para la protección adicional contra la combustión prologada por un lado.DA-SB- T - –
Apagallamas en línea a prueba de detonaciones con dos sensores de temperatura integrados* para la protección adicional contra la combustión a corto plazo en ambos lados.DA-SB- TB - –
Apagallamas en línea a prueba de detonaciones con camisa de calefacciónDA-SB- H -
Apagallamas especiales adicionales bajo demanda
*Termómetro de resistencia para el equipo grupo II, categoría (1) 2 (GII cat. (1) 2)
Selección de materiales para la vivienda
| Modelo | A | B | C |
| Cuerpo | Acero | Acero inox | Hastelloy |
| Camisa de calefacción (DA-SB-(T)-H-...) | Acero | Acero inox | Acero inox |
| Junta | PTFE | PTFE | PTFE |
| Unidad apagallamas | A, B | B, C, D | D |
El cuerpo también está disponible en acero con recubrimiento ECTFE.
Materiales especiales bajo demanda
Combinación de materiales para la unidad apagallamas
| Modelo | A | B | C | D |
| FLAMEFILTER® Jaula | Acero | Acero inox | Acero inox | Hastelloy |
| FLAMEFILTER®* | Acero inox | Acero inox | Hastelloy | Hastelloy |
| Espaciador | Acero inox | Acero inox | Hastelloy | Hastelloy |
**Los discos de filtro FLAMEFILTER® también están disponibles en los materials tántalo, inconel, cobre, etc. cuando se utilizan los materiales en el listado para el cuerpo y la jaula.
Materiales especiales bajo demanda
Diagrama de flujo volumétrico
Los diagramas de flujo volumétrico han sido determinados con un banco de pruebas de caudal calibrado y certifi - cado por TÜV. El flujo volumétrico V. en [m³/h] y el CFH se refi eren a las condiciones estándar de referencia de aire según ISO 6358 (20°C, 1bar). La conversión a otras densidades y temperaturas están referidas en el Vol. 1: “Fundamentos Técnicos”.
