LDA-WF(W)

The device Equipamento A device is a pipe component that influences the media flow by opening, closing, or partially shutting off the flow channel or by dividing or mixing the media flow. is installed outside the container in the filling and drain lines. If the explosive atmosphereis ignited, the device prevents the combustion from traveling into the tank. The PROTEGO® LDA-WF(W) Series of Liquid Detonation Flame Arresters combines the classic PROTEGO® Flame Arrester design with the siphon principle in which the liquid product serves as a barrier to flame propagation.

The application range for the device is a product vapor/air mixture temperature of up to +60°C / 140°F and an absolute pressure up to 1.1 bar / 15.9 psi. Devices with special approval for higher temperatures are available upon request. This covers all possible operating conditions of empty lines for flammable liquids. The liquid detonation arrester Corta-chamas à prova de detonação Flame arrester designed to prevent the transmission of a detonation. is designed for pressures of up to 10 bar / 145 psi, resists explosion Explosão Abrupt oxidation or decomposition reaction producing an increase in temperature, pressure, or in both simultaneously. pressure, and provides protection for almost all flammable liquids. The device is approved for explosion groups IIA to IIB3 (NEC group D to C MESG ≥ 0.65 mm). Special designs with a cleaning cover for highly viscous liquids can be provided. EU conformity according to the currently valid ATEX directive. Approvals according to other national/international regulations on request.
