FA-I-PTFE

When installing the Deflagration Flame Arrester make sure that the distance between potential ignition sources and the location of the installed device Equipamento A device is a pipe component that influences the media flow by opening, closing, or partially shutting off the flow channel or by dividing or mixing the media flow. , the L/D ratio (pipe length/pipe diameter), does not exceed the value of 50. The Deflagration Flame Arrester is symmetrical and offers bidirectional flame transmission protection.

The Deflagration Flame Arrester PROTEGO® FA-I-PTFE can be used for explosion Explosão Abrupt oxidation or decomposition reaction producing an increase in temperature, pressure, or in both simultaneously. group IIA (NEC group D). The standard design is approved at an operating temperature Operating temperature Temperature reached when the equipment is operating under design conditions. up to +60°C / 140°F. The maximum allowable operating pressure Pressão operacional Operating pressure is the pressure existing at normal operating conditions within the system being protected. depends on nominal diameter (DN) and nominal size Dimensão nominal The nominal size is an alphanumeric designation of size for components in a piping system, used for reference purposes, comprising the letters DN followed by a dimensionless integer that is indirectly related to the physical size of the bore or outside diameter of the connections, expessed in millimeters. (NG) and amounts to a maximum of 1.6 bar / 23.2 psi absolute (for DN 100 / 4” and DN 150 / 6” see table 3). EU conformity according to the currently valid ATEX directive. Approvals according to other national/international regulations on request.
